Analytics OData API Reference

Read-only, tenant-isolated OData v4 interface for Mesh analytics data. Browse the entity sets below and query them with standard OData options (for example from Power BI Desktop via Get Data → OData Feed).

Authentication

Method: OAuth 2.0 / OIDC (user-authenticated)

The API is read-only and strictly tenant-isolated. Requests are authenticated with organization-approved user credentials (SSO / OAuth2 / OIDC), aligned with Mesh Dashboard authentication; each dataset is scoped to a single tenant. Send the bearer token in the Authorization header.

Connecting Power BI

The feed is designed to be consumed directly by Power BI Desktop.

1. Choose Get Data → OData Feed.

2. Enter your feed URL:

   https://<your-mesh-host>/api/analytics/v1?tenant=<your-domain>

   If your organization has a dedicated Mesh subdomain, the tenant is resolved from the hostname and you can omit ?tenant= entirely.

3. When prompted for credentials, choose Organizational account and sign in. Anonymous and Basic authentication are not supported.

4. Power BI reads the service metadata and lists every entity set. Select the tables you need, then choose Transform data or Load.

Power BI follows @odata.nextLink automatically, so large entity sets import without any special pagination setup. Very large imports are still bound by Power BI's own dataset-size and refresh-timeout limits.

What the main entity sets describe

Mesh maps your estate as three connected things — your software, the cryptography it uses, and the machines it runs on. Each entity set below is flat and readable on its own, so you rarely need to join tables:

• SoftwareAssets — your software components, and the application and project each belongs to.
• SoftwareDependencies — what each component depends on, both ends inline.
• SoftwareCrypto — the cryptography each component uses, with any policy violations.
• CryptoElements — every cryptographic element and its post-quantum rating.
• MachineAssets — your machines (servers, VMs, endpoints) and their risk.
• MachineSoftwareCorrelations — which software runs on which machine, both ends inline.

Policy violations appear right on the software and crypto rows — violating_algorithms names the non-compliant algorithms and violation_count counts them — so a single filter finds everything that is out of policy.

Worked examples

Each example is a Power Query (M) formula. After connecting with your Organizational account (see Connecting Power BI), open Home → Transform data, add a Blank query, and paste the formula into the formula bar (or Advanced Editor). Replace <your-mesh-host> with your Mesh host and <your-domain> with your tenant domain, then fill in the remaining <...> placeholders with your own values. Drop the leading tenant=<your-domain>& only if your organization has a dedicated Mesh subdomain that resolves the tenant from the hostname.

Software whose cryptography violates policy, with the offending algorithms listed inline — join-free, straight from SoftwareCrypto:

= OData.Feed("https://<your-mesh-host>/api/analytics/v1/SoftwareCrypto?tenant=<your-domain>&$filter=violation_count gt 0&$select=software_name,software_version,software_purl,crypto_name,violating_algorithms,violation_count")

Everything a single component depends on:

= OData.Feed("https://<your-mesh-host>/api/analytics/v1/SoftwareDependencies?tenant=<your-domain>&$filter=software_key eq '<component-key>'&$select=software_name,depends_on_name,depends_on_version,depends_on_purl")

One application's bill of materials, rolled up by parent component:

= OData.Feed("https://<your-mesh-host>/api/analytics/v1/SoftwareAssets?tenant=<your-domain>&$filter=project_key eq '<project-key>'&$select=parent_key,software_name,software_version,purl&$orderby=parent_key,software_name")

Every piece of software installed on a given machine, with its risk and compliance status:

= OData.Feed("https://<your-mesh-host>/api/analytics/v1/MachineSoftwareCorrelations?tenant=<your-domain>&$filter=machine_id eq '<machine-id>'&$select=machine_name,software_name,software_version,software_risk_score,software_compliance_status")

Relating the entity sets

If you build a Power BI model across several tables, these are the keys:

Relationship	Join on
Component to its parent application	SoftwareAssets.parent_id = SoftwareAssets.software_id
Dependency edge to component	SoftwareDependencies.software_key = SoftwareAssets.software_key
Crypto element to its component	CryptoElements.parent_id = SoftwareAssets.software_id
Crypto usage to its component	SoftwareCrypto.software_key = SoftwareAssets.software_key
Everything in one bill of materials	project_key, on all of the above

Where parent_id is not populated, fall back to matching parent_key against software_key.

Entity sets

Entity set	Entity type
Agents	Agent
AgentsHistory	AgentsHistory
CryptoElements	CryptoElement
CryptoElementsHistory	CryptoElementsHistory
MachineAssets	MachineAsset
MachineAssetsHistory	MachineAssetsHistory
MachineSoftwareCorrelations	MachineSoftwareCorrelation
MachineSoftwareCorrelationsHistory	MachineSoftwareCorrelationsHistory
RiskDetails	RiskDetail
RiskDetailsHistory	RiskDetailsHistory
SoftwareAssets	SoftwareAsset
SoftwareAssetsHistory	SoftwareAssetsHistory
SoftwareCrypto	SoftwareCrypto
SoftwareCryptoHistory	SoftwareCryptoHistory
SoftwareDependencies	SoftwareDependency
SoftwareDependenciesHistory	SoftwareDependenciesHistory

Entity types

Agent

Property	Description	Nullable	Key
id	Unique identifier.	Yes	No
agent_id	Unique identifier of the Mesh agent.	No	Yes
agent_key	Stable natural key for the agent.	Yes	No
provider	Source the data was ingested from (for example, servicenowcmdb or offline).	Yes	No
display_name	Human-readable display name.	Yes	No
agent_type	Kind of agent.	Yes	No
external_id	Identifier of the record in the source system it was ingested from.	Yes	No
app_external_id	External identifier of the associated application.	Yes	No
owner_id	Identifier of the owning user.	Yes	No
owner_key	Natural key of the owner.	Yes	No
creator_id	Identifier of the user or process that created the record.	Yes	No
creator_key	Natural key of the creator.	Yes	No
executor_id	Identifier of the executor.	Yes	No
executor_key	Natural key of the executor.	Yes	No
score	Computed score.	Yes	No
score_aggregated	Aggregated score across related items.	Yes	No
attributes	Additional attributes, as structured JSON.	Yes	No
metadata	Additional metadata from the source system, as structured JSON.	Yes	No
top_risk_description	Plain-language description of the highest-severity risk on this item.	Yes	No
top_risk_remediation	Recommended remediation for the highest-severity risk.	Yes	No
computed_at	When Mesh last computed this row.	Yes	No
valid_from	Start of the period this version of the row is valid for.	Yes	No
valid_to	End of the period this version is valid for; empty for the current row.	Yes	No
is_current	True for the latest version of the row.	Yes	No

AgentsHistory

Agents as they were on a past date. Add a snapshot_date filter to choose the day — it is required, and without it the query returns no rows.

Property	Description	Nullable	Key
id	Unique identifier.	No	No
agent_id	Unique identifier of the Mesh agent.	No	Yes
agent_key	Stable natural key for the agent.	Yes	No
provider	Source the data was ingested from (for example, servicenowcmdb or offline).	Yes	No
display_name	Human-readable display name.	Yes	No
agent_type	Kind of agent.	Yes	No
external_id	Identifier of the record in the source system it was ingested from.	Yes	No
app_external_id	External identifier of the associated application.	Yes	No
owner_id	Identifier of the owning user.	Yes	No
owner_key	Natural key of the owner.	Yes	No
creator_id	Identifier of the user or process that created the record.	Yes	No
creator_key	Natural key of the creator.	Yes	No
executor_id	Identifier of the executor.	Yes	No
executor_key	Natural key of the executor.	Yes	No
score	Computed score.	Yes	No
score_aggregated	Aggregated score across related items.	Yes	No
attributes	Additional attributes, as structured JSON.	Yes	No
metadata	Additional metadata from the source system, as structured JSON.	Yes	No
top_risk_description	Plain-language description of the highest-severity risk on this item.	Yes	No
top_risk_remediation	Recommended remediation for the highest-severity risk.	Yes	No
computed_at	When Mesh last computed this row.	Yes	No
valid_from	Start of the period this version of the row is valid for.	No	No
valid_to	End of the period this version is valid for; empty for the current row.	Yes	No
is_current	True for the latest version of the row.	No	No
snapshot_date	The date this row's data reflects (its snapshot date).	No	Yes

CryptoElement

Property	Description	Nullable	Key
crypto_element_id	System-assigned unique identifier for the cryptographic element.	No	Yes
name	Name of the cryptographic element (for example, a certificate or key).	Yes	No
external_id	Identifier of the record in the source system it was ingested from.	Yes	No
crypto_category	Category of the cryptographic element, such as Certificate or Key.	Yes	No
algorithms	Algorithms detected in this element, as structured JSON.	Yes	No
expiration_date	Date the element expires.	Yes	No
machine_asset_id	Identifier of the machine this cryptographic element was found on.	Yes	No
machine_asset_name	Name of the machine this cryptographic element was found on.	Yes	No
platform	Operating system or platform (for example, Amazon Linux 2023).	Yes	No
owner_id	Identifier of the owning user.	Yes	No
owner_org_names	Names of the owning organizations.	Yes	No
location_names	Locations associated with the asset.	Yes	No
risk_score	Computed risk score; higher is riskier.	Yes	No
state	Lifecycle state code.	Yes	No
status	Status of the item, such as Active.	Yes	No
certificate_template_name	Certificate template the item was issued from.	Yes	No
signature_algorithm	Signature algorithm (certificates).	Yes	No
public_key_algorithm	Public-key algorithm (certificates).	Yes	No
hashing_algorithm	Hashing algorithm (certificates).	Yes	No
key_size	Key size, in bits.	Yes	No
serial_number	Certificate serial number.	Yes	No
issuer_dn	Certificate issuer distinguished name.	Yes	No
owner_name	Name of the owner.	Yes	No
owner_email	Email address of the owner.	Yes	No
owner_group	Owning group.	Yes	No
risk_profiles	Comma-separated risk categories that apply (for example, nonCompliance.PQC, orphan.noOwner).	Yes	No
top_risk_description	Plain-language description of the highest-severity risk on this item.	Yes	No
top_risk_remediation	Recommended remediation for the highest-severity risk.	Yes	No
total_risks	Total number of risk findings on this item.	Yes	No
expiration_timestamp	Exact timestamp at which the element expires.	Yes	No
computed_at	When Mesh last computed this row.	Yes	No
owner_org_ids	Identifiers of the owning organizations.	Yes	No
provider	Source the data was ingested from (for example, servicenowcmdb or offline).	Yes	No
valid_from	Start of the period this version of the row is valid for.	Yes	No
valid_to	End of the period this version is valid for; empty for the current row.	Yes	No
is_current	True for the latest version of the row.	Yes	No
violating_algorithms	The specific algorithms on this item that violate the active crypto policy, each with its status — for example, RSA (PROHIBITED); SHA-1 (DEPRECATED). Empty when the item has no violations.	Yes	No
violation_count	Number of policy-violating algorithms on this item. Filter for a value above 0 to find non-compliant items.	Yes	No
parent_id	System identifier of the parent application this component rolls up to.	Yes	No
parent_key	Natural key of the parent application. Use it to roll a component up to the application that contains it.	Yes	No
project_key	Groups everything in one bill of materials (project to application to components).	Yes	No
nist_quantum_security_level	NIST post-quantum security level (0-5). Lower is more quantum-vulnerable; filter for a value below 3 to find weak cryptography.	Yes	No
crypto_primitive	Cryptographic primitive, such as signature, encryption, or hash.	Yes	No

CryptoElementsHistory

Cryptographic elements as they were on a past date. Add a snapshot_date filter to choose the day — it is required, and without it the query returns no rows.

Property	Description	Nullable	Key
crypto_element_id	System-assigned unique identifier for the cryptographic element.	No	Yes
name	Name of the cryptographic element (for example, a certificate or key).	Yes	No
external_id	Identifier of the record in the source system it was ingested from.	No	No
crypto_category	Category of the cryptographic element, such as Certificate or Key.	Yes	No
algorithms	Algorithms detected in this element, as structured JSON.	Yes	No
expiration_date	Date the element expires.	Yes	No
machine_asset_id	Identifier of the machine this cryptographic element was found on.	Yes	No
machine_asset_name	Name of the machine this cryptographic element was found on.	Yes	No
platform	Operating system or platform (for example, Amazon Linux 2023).	Yes	No
owner_id	Identifier of the owning user.	Yes	No
owner_org_names	Names of the owning organizations.	Yes	No
location_names	Locations associated with the asset.	Yes	No
risk_score	Computed risk score; higher is riskier.	Yes	No
state	Lifecycle state code.	Yes	No
status	Status of the item, such as Active.	Yes	No
certificate_template_name	Certificate template the item was issued from.	Yes	No
signature_algorithm	Signature algorithm (certificates).	Yes	No
public_key_algorithm	Public-key algorithm (certificates).	Yes	No
hashing_algorithm	Hashing algorithm (certificates).	Yes	No
key_size	Key size, in bits.	Yes	No
serial_number	Certificate serial number.	Yes	No
issuer_dn	Certificate issuer distinguished name.	Yes	No
owner_name	Name of the owner.	Yes	No
owner_email	Email address of the owner.	Yes	No
owner_group	Owning group.	Yes	No
risk_profiles	Comma-separated risk categories that apply (for example, nonCompliance.PQC, orphan.noOwner).	Yes	No
top_risk_description	Plain-language description of the highest-severity risk on this item.	Yes	No
top_risk_remediation	Recommended remediation for the highest-severity risk.	Yes	No
total_risks	Total number of risk findings on this item.	Yes	No
expiration_timestamp	Exact timestamp at which the element expires.	Yes	No
computed_at	When Mesh last computed this row.	Yes	No
snapshot_date	The date this row's data reflects (its snapshot date).	No	Yes
owner_org_ids	Identifiers of the owning organizations.	Yes	No
provider	Source the data was ingested from (for example, servicenowcmdb or offline).	No	No
valid_from	Start of the period this version of the row is valid for.	Yes	No
valid_to	End of the period this version is valid for; empty for the current row.	Yes	No
is_current	True for the latest version of the row.	Yes	No
violating_algorithms	The specific algorithms on this item that violate the active crypto policy, each with its status — for example, RSA (PROHIBITED); SHA-1 (DEPRECATED). Empty when the item has no violations.	Yes	No
violation_count	Number of policy-violating algorithms on this item. Filter for a value above 0 to find non-compliant items.	Yes	No
parent_id	System identifier of the parent application this component rolls up to.	Yes	No
parent_key	Natural key of the parent application. Use it to roll a component up to the application that contains it.	Yes	No
project_key	Groups everything in one bill of materials (project to application to components).	Yes	No
nist_quantum_security_level	NIST post-quantum security level (0-5). Lower is more quantum-vulnerable; filter for a value below 3 to find weak cryptography.	Yes	No
crypto_primitive	Cryptographic primitive, such as signature, encryption, or hash.	Yes	No

MachineAsset

Property	Description	Nullable	Key
machine_id	Unique identifier of the machine asset.	No	Yes
name	Name of the machine (for example, its hostname).	Yes	No
machine_type	Kind of machine, such as vm or laptop.	Yes	No
os	Operating system and version.	Yes	No
manufacturer	Hardware manufacturer.	Yes	No
external_id	Identifier of the record in the source system it was ingested from.	Yes	No
owner_id	Identifier of the owning user.	Yes	No
owner_org_names	Names of the owning organizations.	Yes	No
location_names	Locations associated with the asset.	Yes	No
risk_score	Computed risk score; higher is riskier.	Yes	No
state	Lifecycle state code.	Yes	No
status	Status of the item, such as Active.	Yes	No
owner_name	Name of the owner.	Yes	No
owner_email	Email address of the owner.	Yes	No
owner_group	Owning group.	Yes	No
risk_profiles	Comma-separated risk categories that apply (for example, nonCompliance.PQC, orphan.noOwner).	Yes	No
top_risk_description	Plain-language description of the highest-severity risk on this item.	Yes	No
top_risk_remediation	Recommended remediation for the highest-severity risk.	Yes	No
total_risks	Total number of risk findings on this item.	Yes	No
computed_at	When Mesh last computed this row.	Yes	No
owner_org_ids	Identifiers of the owning organizations.	Yes	No
provider	Source the data was ingested from (for example, servicenowcmdb or offline).	Yes	No
attributes	Additional attributes, as structured JSON.	Yes	No
metadata	Additional metadata from the source system, as structured JSON.	Yes	No
valid_from	Start of the period this version of the row is valid for.	Yes	No
valid_to	End of the period this version is valid for; empty for the current row.	Yes	No
is_current	True for the latest version of the row.	Yes	No

MachineAssetsHistory

Machines as they were on a past date. Add a snapshot_date filter to choose the day — it is required, and without it the query returns no rows.

Property	Description	Nullable	Key
machine_id	Unique identifier of the machine asset.	No	Yes
name	Name of the machine (for example, its hostname).	Yes	No
machine_type	Kind of machine, such as vm or laptop.	Yes	No
os	Operating system and version.	No	No
manufacturer	Hardware manufacturer.	Yes	No
external_id	Identifier of the record in the source system it was ingested from.	No	No
owner_id	Identifier of the owning user.	Yes	No
owner_org_names	Names of the owning organizations.	Yes	No
location_names	Locations associated with the asset.	Yes	No
risk_score	Computed risk score; higher is riskier.	Yes	No
state	Lifecycle state code.	Yes	No
status	Status of the item, such as Active.	Yes	No
owner_name	Name of the owner.	Yes	No
owner_email	Email address of the owner.	Yes	No
owner_group	Owning group.	Yes	No
risk_profiles	Comma-separated risk categories that apply (for example, nonCompliance.PQC, orphan.noOwner).	Yes	No
top_risk_description	Plain-language description of the highest-severity risk on this item.	Yes	No
top_risk_remediation	Recommended remediation for the highest-severity risk.	Yes	No
total_risks	Total number of risk findings on this item.	Yes	No
computed_at	When Mesh last computed this row.	Yes	No
snapshot_date	The date this row's data reflects (its snapshot date).	No	Yes
owner_org_ids	Identifiers of the owning organizations.	Yes	No
provider	Source the data was ingested from (for example, servicenowcmdb or offline).	No	No
attributes	Additional attributes, as structured JSON.	Yes	No
metadata	Additional metadata from the source system, as structured JSON.	Yes	No
valid_from	Start of the period this version of the row is valid for.	Yes	No
valid_to	End of the period this version is valid for; empty for the current row.	Yes	No
is_current	True for the latest version of the row.	Yes	No

MachineSoftwareCorrelation

Property	Description	Nullable	Key
correlation_id	Unique identifier linking a machine to the software installed on it.	No	Yes
machine_id	Unique identifier of the machine asset.	Yes	No
machine_name	Name of the machine (for example, its hostname).	Yes	No
machine_type	Kind of machine, such as vm or laptop.	Yes	No
machine_os	Operating system of the machine.	Yes	No
software_id	System-assigned unique identifier for the software component.	Yes	No
software_name	Component name (for example, spring-core).	Yes	No
software_version	Component version.	Yes	No
software_vendor	Publisher or vendor of the component.	Yes	No
install_date	Date the software was installed on the machine.	Yes	No
install_date_source	How the install date was determined.	Yes	No
machine_risk_score	Risk score of the machine; higher is riskier.	Yes	No
software_risk_score	Risk score of the software; higher is riskier.	Yes	No
combined_risk_score	Combined risk score for this machine-and-software pairing.	Yes	No
software_compliance_status	Whether the installed software meets policy (for example, compliant, non_compliant, or unknown).	Yes	No
machine_owner_id	Identifier of the machine's owner.	Yes	No
software_owner_id	Identifier of the software's owner.	Yes	No
machine_owner_org_ids	Identifiers of the machine owner's organizations.	Yes	No
machine_owner_org_names	Names of the machine owner's organizations.	Yes	No
software_owner_org_ids	Identifiers of the software owner's organizations.	Yes	No
software_owner_org_names	Names of the software owner's organizations.	Yes	No
location_names	Locations associated with the asset.	Yes	No
computed_at	When Mesh last computed this row.	Yes	No
machine_provider	Source the machine record was ingested from.	Yes	No
software_provider	Source the software record was ingested from.	Yes	No
machine_attributes	Machine attributes such as CPU, memory, and serial number, as structured JSON.	Yes	No
machine_metadata	Machine metadata from the source system, as structured JSON.	Yes	No
valid_from	Start of the period this version of the row is valid for.	Yes	No
valid_to	End of the period this version is valid for; empty for the current row.	Yes	No
is_current	True for the latest version of the row.	Yes	No

MachineSoftwareCorrelationsHistory

Machine-to-software links as they were on a past date. Add a snapshot_date filter to choose the day — it is required, and without it the query returns no rows.

Property	Description	Nullable	Key
correlation_id	Unique identifier linking a machine to the software installed on it.	No	Yes
machine_id	Unique identifier of the machine asset.	Yes	No
machine_name	Name of the machine (for example, its hostname).	Yes	No
machine_type	Kind of machine, such as vm or laptop.	Yes	No
machine_os	Operating system of the machine.	Yes	No
machine_provider	Source the machine record was ingested from.	Yes	No
machine_attributes	Machine attributes such as CPU, memory, and serial number, as structured JSON.	Yes	No
machine_metadata	Machine metadata from the source system, as structured JSON.	Yes	No
software_id	System-assigned unique identifier for the software component.	Yes	No
software_name	Component name (for example, spring-core).	Yes	No
software_version	Component version.	Yes	No
software_vendor	Publisher or vendor of the component.	Yes	No
software_provider	Source the software record was ingested from.	Yes	No
install_date	Date the software was installed on the machine.	Yes	No
install_date_source	How the install date was determined.	Yes	No
machine_risk_score	Risk score of the machine; higher is riskier.	Yes	No
software_risk_score	Risk score of the software; higher is riskier.	Yes	No
combined_risk_score	Combined risk score for this machine-and-software pairing.	Yes	No
software_compliance_status	Whether the installed software meets policy (for example, compliant, non_compliant, or unknown).	Yes	No
machine_owner_id	Identifier of the machine's owner.	Yes	No
machine_owner_org_ids	Identifiers of the machine owner's organizations.	Yes	No
machine_owner_org_names	Names of the machine owner's organizations.	Yes	No
software_owner_id	Identifier of the software's owner.	Yes	No
software_owner_org_ids	Identifiers of the software owner's organizations.	Yes	No
software_owner_org_names	Names of the software owner's organizations.	Yes	No
location_names	Locations associated with the asset.	Yes	No
computed_at	When Mesh last computed this row.	Yes	No
snapshot_date	The date this row's data reflects (its snapshot date).	No	Yes

RiskDetail

Property	Description	Nullable	Key
risk_id	Unique identifier of the risk finding.	No	Yes
risk_category	Category of the risk.	Yes	No
risk_profile	The risk category this finding belongs to.	No	Yes
risk_source	Where the risk was detected.	Yes	No
score	Computed score.	Yes	No
risk_type	Type of risk.	Yes	No
description	Plain-language description of the risk.	Yes	No
remediation	Recommended remediation for the risk.	Yes	No
metadata	Additional metadata from the source system, as structured JSON.	Yes	No
snapshot_date	The date this row's data reflects (its snapshot date).	Yes	No
computed_at	When Mesh last computed this row.	Yes	No
valid_from	Start of the period this version of the row is valid for.	Yes	No
valid_to	End of the period this version is valid for; empty for the current row.	Yes	No
is_current	True for the latest version of the row.	Yes	No

RiskDetailsHistory

Risk findings as they were on a past date. Add a snapshot_date filter to choose the day — it is required, and without it the query returns no rows.

Property	Description	Nullable	Key
risk_id	Unique identifier of the risk finding.	No	Yes
risk_category	Category of the risk.	No	No
risk_profile	The risk category this finding belongs to.	No	Yes
risk_source	Where the risk was detected.	Yes	No
score	Computed score.	Yes	No
risk_type	Type of risk.	Yes	No
description	Plain-language description of the risk.	Yes	No
remediation	Recommended remediation for the risk.	Yes	No
metadata	Additional metadata from the source system, as structured JSON.	Yes	No
snapshot_date	The date this row's data reflects (its snapshot date).	No	Yes
computed_at	When Mesh last computed this row.	Yes	No
valid_from	Start of the period this version of the row is valid for.	Yes	No
valid_to	End of the period this version is valid for; empty for the current row.	Yes	No
is_current	True for the latest version of the row.	Yes	No

SoftwareAsset

Property	Description	Nullable	Key
software_id	System-assigned unique identifier for the software component.	No	Yes
software_name	Component name (for example, spring-core).	Yes	No
software_version	Component version.	Yes	No
software_vendor	Publisher or vendor of the component.	Yes	No
external_id	Identifier of the record in the source system it was ingested from.	Yes	No
owner_id	Identifier of the owning user.	Yes	No
owner_org_names	Names of the owning organizations.	Yes	No
location_names	Locations associated with the asset.	Yes	No
risk_score	Computed risk score; higher is riskier.	Yes	No
installed_machines	Number of machines the component is installed on.	Yes	No
platform	Operating system or platform (for example, Amazon Linux 2023).	Yes	No
owner_name	Name of the owner.	Yes	No
owner_email	Email address of the owner.	Yes	No
owner_group	Owning group.	Yes	No
risk_profiles	Comma-separated risk categories that apply (for example, nonCompliance.PQC, orphan.noOwner).	Yes	No
top_risk_description	Plain-language description of the highest-severity risk on this item.	Yes	No
top_risk_remediation	Recommended remediation for the highest-severity risk.	Yes	No
total_risks	Total number of risk findings on this item.	Yes	No
snapshot_date	The date this row's data reflects (its snapshot date).	Yes	No
computed_at	When Mesh last computed this row.	Yes	No
owner_org_ids	Identifiers of the owning organizations.	Yes	No
provider	Source the data was ingested from (for example, offline for uploaded SBOM/CBOM data). The SBOM hierarchy columns (parent_key, project_key, purl) populate only on offline rows.	Yes	No
valid_from	Start of the period this version of the row is valid for.	Yes	No
valid_to	End of the period this version is valid for; empty for the current row.	Yes	No
is_current	True for the latest version of the row.	Yes	No
status	Status of the item, such as Active.	Yes	No
type	Type classification of the component.	Yes	No
product	Product the component belongs to.	Yes	No
violating_algorithms	The specific algorithms on this item that violate the active crypto policy, each with its status — for example, RSA (PROHIBITED); SHA-1 (DEPRECATED). Empty when the item has no violations.	Yes	No
violation_count	Number of policy-violating algorithms on this item. Filter for a value above 0 to find non-compliant items.	Yes	No
software_key	Stable natural key for the component. Use it to join dependency and crypto rows back to this asset.	Yes	No
software_type	Kind of software, such as library or application.	Yes	No
parent_id	System identifier of the parent application this component rolls up to.	Yes	No
parent_key	Natural key of the parent application. Use it to roll a component up to the application that contains it.	Yes	No
project_key	Groups everything in one bill of materials (project to application to components).	Yes	No
purl	Package URL (purl) — the canonical package identity, for matching against external vulnerability sources.	Yes	No

SoftwareAssetsHistory

Software components as they were on a past date. Add a snapshot_date filter to choose the day — it is required, and without it the query returns no rows.

Property	Description	Nullable	Key
software_id	System-assigned unique identifier for the software component.	No	Yes
software_name	Component name (for example, spring-core).	Yes	No
software_version	Component version.	Yes	No
software_vendor	Publisher or vendor of the component.	Yes	No
external_id	Identifier of the record in the source system it was ingested from.	Yes	No
owner_id	Identifier of the owning user.	Yes	No
owner_org_names	Names of the owning organizations.	Yes	No
location_names	Locations associated with the asset.	Yes	No
risk_score	Computed risk score; higher is riskier.	Yes	No
installed_machines	Number of machines the component is installed on.	Yes	No
platform	Operating system or platform (for example, Amazon Linux 2023).	Yes	No
owner_name	Name of the owner.	Yes	No
owner_email	Email address of the owner.	Yes	No
owner_group	Owning group.	Yes	No
risk_profiles	Comma-separated risk categories that apply (for example, nonCompliance.PQC, orphan.noOwner).	Yes	No
top_risk_description	Plain-language description of the highest-severity risk on this item.	Yes	No
top_risk_remediation	Recommended remediation for the highest-severity risk.	Yes	No
total_risks	Total number of risk findings on this item.	Yes	No
snapshot_date	The date this row's data reflects (its snapshot date).	No	Yes
computed_at	When Mesh last computed this row.	Yes	No
owner_org_ids	Identifiers of the owning organizations.	Yes	No
provider	Source the data was ingested from (for example, offline for uploaded SBOM/CBOM data). The SBOM hierarchy columns (parent_key, project_key, purl) populate only on offline rows.	Yes	No
valid_from	Start of the period this version of the row is valid for.	Yes	No
valid_to	End of the period this version is valid for; empty for the current row.	Yes	No
is_current	True for the latest version of the row.	Yes	No
status	Status of the item, such as Active.	Yes	No
type	Type classification of the component.	Yes	No
product	Product the component belongs to.	Yes	No
violating_algorithms	The specific algorithms on this item that violate the active crypto policy, each with its status — for example, RSA (PROHIBITED); SHA-1 (DEPRECATED). Empty when the item has no violations.	Yes	No
violation_count	Number of policy-violating algorithms on this item. Filter for a value above 0 to find non-compliant items.	Yes	No
software_key	Stable natural key for the component. Use it to join dependency and crypto rows back to this asset.	Yes	No
software_type	Kind of software, such as library or application.	Yes	No
parent_id	System identifier of the parent application this component rolls up to.	Yes	No
parent_key	Natural key of the parent application. Use it to roll a component up to the application that contains it.	Yes	No
project_key	Groups everything in one bill of materials (project to application to components).	Yes	No
purl	Package URL (purl) — the canonical package identity, for matching against external vulnerability sources.	Yes	No

SoftwareCrypto

Property	Description	Nullable	Key
software_crypto_id	Unique identifier for this component-to-crypto link row.	Yes	No
software_id	System-assigned unique identifier for the software component.	Yes	No
software_key	Stable natural key for the component. Use it to join dependency and crypto rows back to this asset.	No	Yes
software_name	Component name (for example, spring-core).	Yes	No
software_version	Component version.	Yes	No
software_purl	Package URL (purl) of the component — the canonical package identity, for matching against external vulnerability sources.	Yes	No
crypto_element_id	System-assigned unique identifier for the cryptographic element.	Yes	No
crypto_element_key	Stable natural key for the cryptographic element.	No	Yes
crypto_name	Name of the cryptographic element linked to the component.	Yes	No
crypto_category	Category of the cryptographic element, such as Certificate or Key.	Yes	No
crypto_primitive	Cryptographic primitive, such as signature, encryption, or hash.	Yes	No
nist_quantum_security_level	NIST post-quantum security level (0-5). Lower is more quantum-vulnerable; filter for a value below 3 to find weak cryptography.	Yes	No
violating_algorithms	The specific algorithms on this item that violate the active crypto policy, each with its status — for example, RSA (PROHIBITED); SHA-1 (DEPRECATED). Empty when the item has no violations.	Yes	No
violation_count	Number of policy-violating algorithms on this item. Filter for a value above 0 to find non-compliant items.	Yes	No
relationship_type	How the component uses the cryptographic element (typically uses).	No	Yes
project_key	Groups everything in one bill of materials (project to application to components).	Yes	No
provider	Source the data was ingested from (for example, servicenowcmdb or offline).	Yes	No
snapshot_date	The date this row's data reflects (its snapshot date).	Yes	No
computed_at	When Mesh last computed this row.	Yes	No
valid_from	Start of the period this version of the row is valid for.	Yes	No
valid_to	End of the period this version is valid for; empty for the current row.	Yes	No
is_current	True for the latest version of the row.	Yes	No

SoftwareCryptoHistory

Component-to-cryptography links as they were on a past date. Add a snapshot_date filter to choose the day — it is required, and without it the query returns no rows.

Property	Description	Nullable	Key
software_crypto_id	Unique identifier for this component-to-crypto link row.	No	No
software_id	System-assigned unique identifier for the software component.	Yes	No
software_key	Stable natural key for the component. Use it to join dependency and crypto rows back to this asset.	No	Yes
software_name	Component name (for example, spring-core).	Yes	No
software_version	Component version.	Yes	No
software_purl	Package URL (purl) of the component — the canonical package identity, for matching against external vulnerability sources.	Yes	No
crypto_element_id	System-assigned unique identifier for the cryptographic element.	Yes	No
crypto_element_key	Stable natural key for the cryptographic element.	No	Yes
crypto_name	Name of the cryptographic element linked to the component.	Yes	No
crypto_category	Category of the cryptographic element, such as Certificate or Key.	Yes	No
crypto_primitive	Cryptographic primitive, such as signature, encryption, or hash.	Yes	No
nist_quantum_security_level	NIST post-quantum security level (0-5). Lower is more quantum-vulnerable; filter for a value below 3 to find weak cryptography.	Yes	No
violating_algorithms	The specific algorithms on this item that violate the active crypto policy, each with its status — for example, RSA (PROHIBITED); SHA-1 (DEPRECATED). Empty when the item has no violations.	Yes	No
violation_count	Number of policy-violating algorithms on this item. Filter for a value above 0 to find non-compliant items.	Yes	No
relationship_type	How the component uses the cryptographic element (typically uses).	No	Yes
project_key	Groups everything in one bill of materials (project to application to components).	Yes	No
provider	Source the data was ingested from (for example, servicenowcmdb or offline).	Yes	No
snapshot_date	The date this row's data reflects (its snapshot date).	No	Yes
computed_at	When Mesh last computed this row.	Yes	No
valid_from	Start of the period this version of the row is valid for.	Yes	No
valid_to	End of the period this version is valid for; empty for the current row.	Yes	No
is_current	True for the latest version of the row.	Yes	No

SoftwareDependency

Property	Description	Nullable	Key
dependency_id	Unique identifier for this dependency-edge row.	Yes	No
software_id	System-assigned unique identifier for the software component.	Yes	No
software_key	Stable natural key for the component. Use it to join dependency and crypto rows back to this asset.	No	Yes
software_name	Component name (for example, spring-core).	Yes	No
software_version	Component version.	Yes	No
software_purl	Package URL (purl) of the component — the canonical package identity, for matching against external vulnerability sources.	Yes	No
depends_on_software_id	System identifier of the component this one depends on.	Yes	No
depends_on_software_key	Natural key of the component this one depends on.	No	Yes
depends_on_name	Name of the component this one depends on.	Yes	No
depends_on_version	Version of the component this one depends on.	Yes	No
depends_on_purl	Package URL (purl) of the component this one depends on.	Yes	No
relationship_type	How the two components are related (typically depends_on).	No	Yes
project_key	Groups everything in one bill of materials (project to application to components).	Yes	No
provider	Source the data was ingested from (for example, servicenowcmdb or offline).	Yes	No
snapshot_date	The date this row's data reflects (its snapshot date).	Yes	No
computed_at	When Mesh last computed this row.	Yes	No
valid_from	Start of the period this version of the row is valid for.	Yes	No
valid_to	End of the period this version is valid for; empty for the current row.	Yes	No
is_current	True for the latest version of the row.	Yes	No

SoftwareDependenciesHistory

Dependency links as they were on a past date. Add a snapshot_date filter to choose the day — it is required, and without it the query returns no rows.

Property	Description	Nullable	Key
dependency_id	Unique identifier for this dependency-edge row.	No	No
software_id	System-assigned unique identifier for the software component.	Yes	No
software_key	Stable natural key for the component. Use it to join dependency and crypto rows back to this asset.	No	Yes
software_name	Component name (for example, spring-core).	Yes	No
software_version	Component version.	Yes	No
software_purl	Package URL (purl) of the component — the canonical package identity, for matching against external vulnerability sources.	Yes	No
depends_on_software_id	System identifier of the component this one depends on.	Yes	No
depends_on_software_key	Natural key of the component this one depends on.	No	Yes
depends_on_name	Name of the component this one depends on.	Yes	No
depends_on_version	Version of the component this one depends on.	Yes	No
depends_on_purl	Package URL (purl) of the component this one depends on.	Yes	No
relationship_type	How the two components are related (typically depends_on).	No	Yes
project_key	Groups everything in one bill of materials (project to application to components).	Yes	No
provider	Source the data was ingested from (for example, servicenowcmdb or offline).	Yes	No
snapshot_date	The date this row's data reflects (its snapshot date).	No	Yes
computed_at	When Mesh last computed this row.	Yes	No
valid_from	Start of the period this version of the row is valid for.	Yes	No
valid_to	End of the period this version is valid for; empty for the current row.	Yes	No
is_current	True for the latest version of the row.	Yes	No

Query options

Option	Description
$filter	Filter the collection by a boolean expression.
$select	Return only the named properties.
$orderby	Sort the collection by one or more properties.
$top	Return at most N records (pagination).
$skip	Skip the first N records (pagination). Deprecated — see the note below.
$skiptoken	Resume from the cursor returned in @odata.nextLink (keyset pagination).
$count	Include the total match count with the response.

$skip is deprecated (max 1,000,000) and will be removed in a future release. Use $skiptoken via @odata.nextLink for keyset pagination. Requests using $skip receive a Deprecation: true response header (RFC 8594).
